DATA COLLECTION WITH FORMULA™ SOFTWARE APPLICATIONS
18
Select the TERMINALS tab to view the following screen. It is recommended that the
FILE NAME for collected data have a .dat extension (default name is TERM001.dat),
followed by the PATH where the data will be uploaded to on the PC.
Select OK in the Formula Control Properties to return to the main SysTools™ screen.
Select CONNECT (the Formula™ will emit a tone).
Now Systools™ is ready to receive data from the terminal.
2.4.2 Prepare Formula™ to upload Data
1. Prepare the Formula™ to upload (transmit) the collected data. From the program
menu on the Formula™; select <F3> to display the File Options menu.
INV MGMT¤
F2=COLLECT
F3=FILE OPTIONS
F4=EXIT
2. Select <F2> to display the Send File menu.
*FILE OPTIONS*
F2=SEND FILE
F3=ERASE FILE
F4=EXIT¤
