hh:mm:ss.xx, with hh representing hours since the master hub was
turned on, mm the minutes, ss the seconds, and xx representing 100ths
of a second.
♦ Group Slot (1)
. Shows the status of module slot 1. If there is a mod-
ule installed in slot 1, this field will display: MII, TP, FX, or Switch as
determined by the type of module installed. If there is no module in-
stalled, the field will display one.”
♦ Group Slot (2)
. Shows the status of module slot 2. If there is a mod-
ule installed in slot 2, this field will display: MII, TP, FX, or Switch as
determined by the type of module installed. If there is no module in-
stalled, the field will display one.”
♦ Group Isolate
. Provides control of the hub current network con-
nection status and allows the system manager to manually isolate a
particular hub as needed and reconnect it later. Toggling the field to
solate” separates the hub data connection from the other hubs.
Toggling the field to econnect” re-establishes the connection. See
egmenting Hubs” earlier in this chapter for more information.
DFE-2600 Stackable Hub - Network Monitoring : Group Configuration Menu
Group ID (1-5) [1]
Group Serial Number: 623000B
Group Position Number:
Group Description: DFE2624i
Group Role: Primary Master
Group Port Capacity: 24
Group Hardware Revision: Rev. 06
Group Master Revision: Rev. 01
Group Status: Up
Group Last Oper Change: 0:1:35.90
Group Slot (1): Switch
Group Slot (2): none
Group Isolate: <Reconnect>
PREV GROUP NEXT GROUP HELP SAVE EXIT
