Controls in detail
Air conditioning
3
̈ To switch off: press the °
switch for normal mode.
The indicator lamp in the switch goes
out.
Air distribution control
Heating
̈
Set temperature selector control 1
(
୴ page 218) as required, but do not
turn the control below the middle po-
sition.
̈ Set airflow control 2 (୴ page 218)
as required, but do not turn the con-
trol below the second speed.
̈ Set the air distribution control as
shown.
̈ Close the center air vents.
̈ Close the air vents.
̈ Open the side air vents half-way and
direct them at the side windows.
Ventilation/cooling
This setting rapidly ventilates/cools the
vehicle interior.
̈ Turn temperature selector control
1 (୴ page 218) to the lowest set-
ting (maximum cooling).
̈ Set airflow control 2 (୴ page 218)
as required, but do not turn the con-
trol below the second speed.
̈ Set air distribution control 5
(
୴ page 218) to h.
Basic setting
