ControlWave I/O Modules and Termination Blocks
DESCRIPTION PART NO.
Remote Termination I/O Modules (PC 850)
16 AI 4-20 mA Internally or Externally powered AI 396352-11-1
16 AI 1-5 V & ext. powered 4-20 (with 250 ohm on input) 396352-12-0
8 AI 4-20 mA Internally or Externally powered AI 396352-13-8
8 AI 1-5 V & ext. powered 4-20 (with 250 ohm on input) 396352-14-6
6 TC B, R, S, J, E, K, T, C, N, + 10 mV 396877-02-8
4 RTD 2, 3, or 4 wire platinum RTD 396878-02-4
8 AO 4-20 mA 396353-11-8
8 AO 1-5 V 396353-12-6
4 AO 4-20 mA 396353-13-4
32 DI Selectable Internally or Externally powered Dry Contact 396357-11-3
16 DI Selectable Internally or Externally powered Dry Contact 396357-12-1
32 DO Open Drain - 500 mA current capability, 30 mS lter 396358-11-0
16 DO Open Drain - 500 mA current capability, 30 mS lter 396358-12-8
12 UDI (High Speed Counter) Both 12 and 6 UDI High speed counters come with selectable 396362-11-7
6 UDI (High Speed Counter) debounce (enabled/disable) @ (0-10 KHz) Low or High speed
counters. Inputs are 24VDC only.
396362-12-5
Remote Terminal Blocks - (replacement fuses & relays can be found on spares page) (PC 851)
4 point AI (Note 1) No fuse 396391-01-0
4 point AI Fused 396391-02-8
2 point AO (Note 1) No fuse 396391-01-0
2 point AO Fused 396391-02-8
8 point DI No fuse 396292-01-6
8 point DI Fused 395622-02-6
8 point DI - 120 Vac No fuse (for internally powered DI module) 395622-04-2
8 point DI - 120 Vac No fuse (for externally powered DI module) 395622-01-8
8 point DO No fuse 396292-01-6
8 point DO Fused 395622-03-4
8 point DO 6 Amp Relay - No fuse 395622-00-0
3 point UDI No fuse 396391-01-0
3 point UDI (Note 2) No fuse protection 396391-02-8
