The software image is contained in a single file with the power-up
diagnostics. It is based on the Nortel Open IP design model and runs on
top of the VxWorks operating system.
The modules are intended to meet overall FIPS 140-2 Level 2
requirements (see Table 2).
Section Section Title Level
1 Cryptographic Module Specification 2
2 Cryptographic Module Ports and Interfaces 2
3 Roles, Services, and Authentication 2
4 Finite State Model 2
5 Physical Security 2
6 Operational Environment N/A
7 Cryptographic Key Management 2
8 EMI/EMC 2
9 Self-tests 2
10 Design Assurance 2
11 Mitigation of Other Attacks N/A
Table 2 – Intended Level Per FIPS 140-2 Section
Module Interfaces
The XSR-1805 provides a number of physical ports:
• Two 10/100BaseT FastEthernet LAN ports
• One console port
• Two PCM slots
• One PCMCIA slot for the optional CompactFlash card
