4.4.9. Map Descriptor Example 6 - Analog Output 2 (Zone and Area Machine)
A write to the Analog Output Data Array which is shared by a BACNet IP Map Descriptor will execute one of multiple scripts on the
Lutron eLumen panel. The value written into the Analog Output Data Array is used as an offset into the Data Array defined under
“DA_Lut_List” to retrieve a script number. Script numbers range from 0 to 65535.
BACNet IP Map Descriptor
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_name, Data_Type, Object_ID, Length, Relinquish_Default
SMD512_AO, Analog_Output, 512, Server, Virtual_BCU_11, AO, 513, 512, 0
Lutron Machine Map Descriptor
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_name, Grafik_Command, DA_Lut_List, DA_Lut_List_Offset, Length, Multi_Scripts_Length
Run_script_512, Analog_Output, 512, AWT, LUT_GRF6_0, run_script_multi, Scr_lst_AO2_512, 0, 1, 10
The Multi_Scripts_Length field is used to indicate the maximum size of the Data Array specified under Data_Array_Name. One Map
Descriptor per object must be defined with a Multi_Scripts_Length value of 1 or greater.
