Chapter 1 Tape Library Components 21
Chapter 1
Figure 3 Locating Cartridges - Top View
C65127
4
567
8
3
2
1
1 1/3 capacity (partial access to Panel 2) 5 Drive column 1 (optional)
2 2/3 capacity (entire access to Panel 2) 6 CAP B (optional)
3 Full capacity (with optional expansion frame) 7 CAP A
4 Drive column 0 8 Panel 12
