HP Docking Station Rear Components
HP Docking Station Rear ComponentsHP Docking Station Rear Components
HP Docking Station Rear Components
1.
Security cable slot
10.
USB 2.0 ports (2)
2.
Monitor stand port
11.
Power connector
3.
Audio-out jack
12.
External monitor port
4.
Mouse Connector
13.
Serial port
5.
Parallel Port
14.
Keyboard connector
6.
Digital Video (DVI-D) port
15.
Audio-in jack
7.
Power light
16.
Composite video port
8.
RJ-11 (modem) jack
17.
S-Video jack
9.
RJ-45 (network) jack
Key Benefits
Key BenefitsKey Benefits
Key Benefits
Desktop convenience with full port replication capability in a space-saving design.
Easy docking system provides port replication and cable management in one product.
Four USB ports allow you to connect more peripherals to make you more productive.
Optional integrated HP/Kensington Cable Lock allows you to secure your docking station and notebook with one lock.
AC adapter included
AC adapter includedAC adapter included
AC adapter included
The HP 2008 Docking Station gives you an energy-efficient 120W Smart AC adapter for your Notebook PC or 150W Smart AC
adapter for your Mobile Workstations that guards against power fluctuations with integrated surge protection. The HP Docking
Station features the same protection with an energy-efficient 120W Smart AC adapter.
QuickSpecs
HP Docking Stations for Performance, Workstation and
HP Docking Stations for Performance, Workstation andHP Docking Stations for Performance, Workstation and
HP Docking Stations for Performance, Workstation and
Balanced Mobility
Balanced MobilityBalanced Mobility
Balanced Mobility
HP Docking Station
DA - 13068 North America — Version 2 — January 16, 2009
Page 11
