HP Advanced Docking Station Rear Components
HP Advanced Docking Station Rear ComponentsHP Advanced Docking Station Rear Components
HP Advanced Docking Station Rear Components
1.
Security cable slot
10.
RJ-11 (modem) jack
2.
Audio-out jack
11.
RJ-45 (network) jack
3.
Mouse connector
12.
USB 2.0 ports (2)
4.
Monitor stand port
13.
Power connector
5.
Parallel port
14.
External monitor port
6.
S-Video jack
15.
Serial port
7.
Composite video port
16.
Keyboard connector
8.
Digital Video (DVI-D) port
17.
Audio-in jack
9.
Power light
Key Benefits
Key BenefitsKey Benefits
Key Benefits
Robust desktop replacement solution for your mobile office with advanced features for future expansion.
Easy docking system provides port replication and cable management, plus expandability through an integrated MultiBay II
expansion bay and ExpressCard slot - all in one product.
Six USB ports allow you to connect more peripherals to make you more productive.
Optional integrated HP/Kensington Cable Lock allows you to secure your docking station, notebook and integrated MultiBay
II drive with one lock.
AC adapter included
AC adapter includedAC adapter included
AC adapter included
The HP Advanced Docking Station with Smart Adapter features a new energy-efficient 135W Smart AC adapter that guards against
power fluctuations with integrated surge protection. The 135W Smart AC adapter can be leveraged across all HP Business
Notebooks and docking stations, providing a cost-effective solution for reducing power consumption and equipment costs.
QuickSpecs
HP Docking Stations for Performance, Workstation and
HP Docking Stations for Performance, Workstation andHP Docking Stations for Performance, Workstation and
HP Docking Stations for Performance, Workstation and
Balanced Mobility
Balanced MobilityBalanced Mobility
Balanced Mobility
HP Advanced Docking Station
DA - 13068 North America — Version 2 — January 16, 2009
Page 15
