User Programmable
Modes
Yes, 15
Anti-Glare
Yes
Anti-Static
Yes
AssetControl
Yes (accessible on HP Compaq Business Desktops featuring Intelligent
Manageability)
Default Color
Temperature
Yes (6500k, 9300k, SRGB, Custom User)
On Screen Display
(OSD)
Controls
Buttons or Switches
Power on/off; 3-button OSD; second level OSD buttons include dual-
input switch, dedicated auto adjust switch
Languages
English, Spanish, French, German, Netherlands, Italian, Japanese,
Simplified Chinese
User Controls
Size and Positioning
Contrast
Brightness
Clock, Clock Phase
Selectable Color Temperature
Serial Number
Mode Displayed
Sleep Timer
Input Selection
Factory Reset
Power
Power Supply
Auto-ranging, 90 to 265 VAC; internal power supply
Input Power
100 ~ 240 VAC
Nominal Current
1.5 A maximum
Frequency
50 ~ 60 Hz
Typical Power
Consumption
< 35 watts
Maximum
< 55 watts
Power Saving
< 2 watts
Off Mode
0 watts (when master power switch is in the off position)
Power Cable Length
74.8 in (1.9 m); non-captive
Mechanical
Dimensions
(H x W x D)
Unpacked w/stand
14.85 min to 18.79 max x 15.9 x 8.78 inches
(37.72 min to 47.72 max x 40.39 x 22.29 cm)
Base area
(Footprint D x W)
8.78 x 11.88 inches (22.29 x 30.18 cm)
Display head only
(Without stand) (H x W x
D)
12.96 x 15.9 x 2.4 inches (32.91 x 40.39 x 6.1
cm)
Weight
Unpacked w/stand
15.6 lbs (7.06 kg)
Unpacked w/o stand
9.26 lbs (4.19 kg)
Packaged
20.5 lbs (9.27 kg)
Bezel width
12.5 mm left and right, 12.75 mm top and bottom
Tilt Range
-4 degrees to +30 degrees
Swivel Range
± 45 degrees horizontal swivel
Height Adjustable
Yes (4 in/100mm adjustment range)
QuickSpecs
HP LP1965 Flat Panel Monitor
Technical Specifications
DA - 12620 Worldwide QuickSpecs — Version 2 — 11.1.2006
Page 3
