Pivot Rotation
Yes, 90 degrees
Base
Ships attached and is removable
Environmental
Temperature –
Operating
41° to 95° F (5° to 35° C)
Temperature –
Non-operating
-4° to 140° F (-20° to 60° C)
Humidity – Operating
20% to 80%
Humidity –
Non-operating
5% to 95%
Altitude – Operating
0 to 12,000 ft (0 to 3,658 m)
Altitude –
Non-operating
0 to 40,000 ft (0 to 12,192 m)
Environmental Data
Eco-Label
Certifications and
Declarations
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
US Energy Star
CECP
Energy Consumption
(in accordance with US
Energy Star test method)
AC Input Voltage at
100 VAC +/- 5 VAC, 50
Hz +/- 3 Hz
AC Input Voltage at
115 VAC +/- 5 VAC, 60
Hz +/- 3 Hz
AC Input Voltage at
230 VAC +/- 5 VAC, 50
Hz +/- 3 Hz
Normal Operation
35.7 watts 35.6 watts 35.1 watts
Sleep
1.08 watts
1.14watts
1.23 watts
Off
0.93 watts 0.94 watts 0.92 watts
Heat Dissipation
*
100 VAC, 50 Hz 115 VAC, 60 Hz 230 VAC, 50 Hz
Normal Operation
121.7 BTU/hr 121.4 BTU/hr 119.7 BTU/hr
Sleep
3.68 BTU/hr 3.89 BTU/hr 4.19 BTU/hr
Off
3.17 BTU/hr 3.21 BTU/hr 3.14 BTU/hr
*NOTE
: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Longevity and
Upgrading
Upgradeability features contained in the product include:
One upstream and four downstream USB ports
Ergonomics
The monitor meets the ergonomic requirement of EN-ISO 13406-2 for
flat panel displays.
Additional Information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) Directive, 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive, 2002/96/EC.
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
Display meets the requirement for low frequency electromagnetic fields
per MPR-II, TCO, and prEN50279 A/B/C.
This product contains 100% recycled materials (by wt.)
This product is 100% recycleable when properly disposed of at end of
QuickSpecs
HP LP1965 Flat Panel Monitor
Technical Specifications
DA - 12620 Worldwide QuickSpecs — Version 2 — 11.1.2006
Page 4
