Monitor MultiSync
®
LCD1770VX Notes
Specifications Monitor
LCD Module Diagonal : 17.0 inch Active matrix; thin film transistor (TFT)
Viewable Image Size : 17.0 inch liquid crystal display (LCD); 0.264 mm dot
Native Resolution (Pixel Count) : 1280 x1024 pitch; 250cd/m
2
white luminence;
500:1 contrast ratio, typical
Input Signal Video : ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI-D
Sync : Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Display Colors 16,194,277 Dependent on display card used.
Maximum Left/Right : 80°/80° (CR>5)
Viewing Angles Up/Down : 85°/75° (CR>5)
Synchronization Horizontal : 31.5 kHz to 81.0 kHz (Analog) Automatically
Range 31.5 kHz to 69.0 KHz (Digital) Automatically
Vertical : 56.0 Hz to 75.0 Hz Automatically
Resolutions Supported 720 x 400*
1
@ 70 Hz
Some systems may not support all modes listed.
640 x 480*
1
@ 60 Hz to 75 Hz
800 x 600*
1
@ 56 Hz to 75 Hz
832 x 624*
1
@ 75 Hz
1024 x 768*
1
@ 60 Hz to 75 Hz
1152 x 864*
1
@ 75 Hz
1152 x 870*
1
@ 75 Hz
1
280 x 1024 @ 60 Hz to 75 Hz (Analog).....NEC DISPLAY SOLUTIONS
1280 x 1024 @60 Hz (Digital) cites recommended resolution
at 60 Hz for optimal display
performance.
Active Display Area Horizontal : 337.9 mm/13.3 inches
Vertical : 270.3 mm/10.6 inches
Power Supply 100 – 240 V~ 50/60 Hz
Current Rating 0.70 - 0.35 A
Dimensions 367 mm (W) x 362.5-472.5 mm (H) x 198.0 mm (D)
14.4 inches (W) x 14.3-18.6 inches (H) x 7.8 inches (D)
Weight 6.1 kg
13.4 lbs
Environmental Considerations
Operating Temperature : 5°C to 35°C/41°F to 95°F
Humidity : 30% to 80%
Feet : 0 to 10,000 Feet
Storage Temperature : -10°C to 60°C/-14°F to 140°F
Humidity : 10% to 85%
Feet : 0 to 30,000 Feet
*
1
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
