Manage the Modem Router and Monitor the Traffic
96
N150 and N300 WiFi DSL Modem Routers
The following table describes the fields of the Connection Status pop-up screen.
Field Description
IP Address The IP address that is assigned by the ISP to the modem router.
Subnet Mask The subnet mask that is assigned by the ISP to the modem router.
Default Gateway The IP address of the default gateway of the ISP that the modem router
communicates with.
DHCP Server The IP address of the DHCP server of the ISP that issues the IP address to the
modem router.
DNS Server The IP address of the Domain Name System (DNS) server of the ISP that provides
translation of network names to IP addresses.
7. To renew the Internet connection when the connection is active, click the Renew button.
8. To terminate the Internet connection when the connection is active, click the Release button.
9. Click the Close Window
button.
The pop-up screen closes.
View the xDSL Line Status and Modem Statistics
The xDSL Line Status screen displays the xDSL line status and modem statistics. You
cannot change these settings.
To view modem router status:
1. Launch an Internet browser from a computer or WiFi device that is connected to the
network.
2. T
ype http://www.routerlogin.net or http://www
.routerlogin.com.
A login screen displays.
3. Enter the user name and password for the modem router.
