PLANET NOVASwitch series
3.4 Submenu :(1) VLAN
Oà enables the port you select
Xà disables the port you select
Use Tab or “U”,”D”,”L”,”R” to move the item which to be change,
press space bar to change it, ”S” for save this configuration
[Port base VLAN]
[1] [2] [3] [4] [5] [6] [7] [8]
[Group 1] O O O O O O O O
[Group 2] x x x x x x x x
[Group 3] x x x x x x x x
[Group 4] x x x x x x x x
[Group 5] x x x x x x x x
[Group 6] x x x x x x x x
[Group 7] x x x x x x x x
[Group 8] x x x x x x x x
member port of trunk group must belong to same VLAN
[Tab] : Move to next item
[Space Bar] : Toggle item
[S] : Save & Exit
[Q] : Quit
[U]:Up, [L]:Left
[D]:Down, [R]:Right
