TABLE OF CONTENTS
The serial tag is a permanently affixed sticker on
which is recorded vital electrical and refrigeration data
about your Traulsen product, as well as the model
and serial number. This tag is located in the upper
right interior compartment on all reach-in/pass-thru
and roll-in/roll-thru refrigerator, freezer and dual-temp
models. For hot food models, this tag is located on
the top of the unit behind the louvers to protect it
from the heat.
I. THE SERIAL TAG
-1-
FORT WORTH, TX.
SERIAL MODEL
VOLTS Hz PH
TOTAL CURRENT AMPS
MINIMUM CIRCUIT AMPS
MAXIMUM OVERCURRENT PROTECTION AMPS
LIGHTS WATTS
HEATERS AMPS
REFRIGERANT TYPE OZ
DESIGN PRESSURE HIGH LOW
REFRIGERANT TYPE OZ
DESIGN PRESSURE HIGH LOW
370-60294-00 REV (A)
READING THE SERIAL TAG
• Serial = The permanent ID# of your Traulsen
• Model = The model # of your Traulsen
• Volts = Voltage
• Hz = Cycle
• PH = Phase
• Total Current = Maximum amp draw
• Minimum Circuit = Minimum circuit ampacity
• Lights = Light wattage
• Heaters = Heater amperage (Hot Food units only)
• Refrigerant = Refrigerant type used
• Design Pressure = High & low side operating
pressures and refrigerant charge
• Agency Labels = Designates agency listings
VII. MICROPROCESSOR CONTROL
a-Control Features Page 5
b-Control Panel Page 6
c-Parts Assembly Page 6
d-Notes To The User Page 7
e-Enter The Customer Access Code Page 7
f-Customer Service Parameters Page 8
g-Adjusting Thermostat Set Point High Page 8
h-Adjusting Thermostat Set Point Low Page 9
i-Changing The Temperature Scale Page 9
j-Setting The 24-Hour Clock Page 10
k-Setting The Date Page 11
l-Setting Daylight Savings Time Page 11
m-Starting A Manual Defrost Page 12
n-Setting Defrost Lockouts Page 13
o-Adjusting The Room Temperature Offset Page 14
p-Viewing Sensor Temperatures Page 14
VIII. TROUBLE SHOOTING GUIDE Page 15
IX. WARRANTY INFORMATION Page 16
X. OTHER
a-Service Information Page 17
b-Spare Parts Page 17
c-Warranty Registration Page 17
XI. PARTS LIST Page 17
XII. INDEX Page 18
I. THE SERIAL TAG Page 1
II. RECEIPT INSPECTION Page 2
III. INSTALLATION
a-Location Page 2
b-Packaging Page 2
c-Installing Legs or Casters Page 2
d-Shelf Pins Page 2
e-Cord & Plug Page 3
f-Power Supply Page 3
g-Wiring Diagram Page 3
h-Clearance Page 3
IV. OPERATION
a-Convertible Cabinets - Intended Use Page 3
b-Convertible Freezer Normal Operation Page 3
b-Using The Convertible Freezer Page 3
V. CARE & MAINTENANCE
a-Cleaning The Condenser Page 4
b-Hinge Replacement Page 4
c-Replacing The Gaskets Page 4
d-Cleaning The Exterior Page 5
e-Cleaning The Interior Page 5
VI. MISC. OPERATIONS
a-Adjusting The Shelves Page 5
