FPM-2150 Series User Manual 2
Chapter 1 Introduction
1.1 Introduction
Advantech's FPM-2150 Series consists of 15" color TFT LCD flat panel
monitors built specifically for industrial applications. With the optional
touchscreen, the FPM-2150 Series is an user-friendly system control
interface.
In addition to its usual application as an LCD panel monitor, the FPM-
2150 Series comes standard with Direct VGA control signal input, mak-
ing it compatible with industrial PCs and workstations.
The OSD (On Screen Display) function allows you to adjust the display
and turn the backlight on and off, a function that is highly appreciated
among experienced users of industrial flat panel monitors.
The whole chassis is made of durable steel, and the front panel is of Al-
Mg with NEMA4/IP65 compliance.
Products in the FPM-2150 Series can also be provided in touch screen
versions (FPM-2150-R and FPM-2150-U). With an 8-wire resistive type
touchscreen, this monitor can be immediately transformed into a remote
control system.
The Advantech FPM-2150 is the ultimate HMI solution for your indus-
trial application.
1.2 Specifications
General
• Construction: Heavy-duty steel chassis
• Front Panel: Al-Mg, NEMA4/IP65 compliant
• Control: OSD (On Screen Display) control pad on front side
• Mounting: Panel, wallmount, rackmount (with rackmount kit), desktop
or VESA Arm
• Dimensions (W x H x D): 383 x 307 x 48.13 mm (15" x 12.09" x 1..9")
• Panel Mount Cut out Dimension (W x H): 373.5 x 297.5 mm (14.7" x
14.71")
• Weight: 4.5 kg (9.9 lb)
