FPM-2150 Series User Manual 14
Appendix A Display Timing Mode & OSD
A.1 Supported Input Timing Modes
The different frequencies below are already programmed in this module,
and the synchronous signal inputs are automatically recognized.
Note 1: Even if the preset timing is entered, some adjustment of func-
tions such as Horizontal period, CLK-delay and display position,
are required. The adjusted values are memorized in every preset
number.
Note 2: This module recognizes the synchronous signals with near preset
timing of the frequency of the HS and Vsync, even in the case
that the signals other than the preset timing that were entered.
Note 3: Because adjustments may not fit, such as differing magnifying
ratios or, in the case that you use it except for the display timing
that was preset.
Table A.1: Supported Input Formats
Vertical Frequencies
Resolution 56 Hz 60 Hz 70 Hz 72 Hz 75 Hz
640 x 480 Yes Yes Yes
720 x 400 Yes
800 x 600 Yes Yes Yes Yes
1024 x 768 Yes Yes Yes
