Specifications and Regulatory Information
Specifications and Regulatory Information
This section lists specifications and characteristics and regulatory information
of the probe adapter.
Specifications
The distinction between specifications and characteristics is described as fol-
lows:
• Specifications describe warranted performance over the temperature range
0
°C to +55°C and relative humidity <95% (unless otherwise noted). All
specifications apply after the temperature of the probe and the probe
adapter has been stabilized after 30 minutes of continuous operation.
• Characteristics provide useful information by giving functional, but
nonwarranted, performance parameters. Characteristics are printed in
italics.
Review the following specifications to ensure that your operating or storage
environment is suitable for the adapter.
Table 2. Environmental Specifications (1 of 2)
Operating Temperature
0
° C to +55°C
Storage Temperature
–40° C to +70°C
Use Indoor
EMC Conducted and radiated
Emission is in compliance with CISPR 11 Class A
and IEC 61326
ESD Tolerance 4kV contact 8kV air discharged
Operational Humidity (type tested)
95% R.H. (non-condensing) at +40
°C (+104°F)
Altitude Up to 4600 meters
