COLOR MONITOR User’s Guide Front Panel Components and Controls
CONTRAST Switch
This control adjusts the contrast of the screen image. Press
CONTRAST switch and then VOLUME(DATA) switch to control the
contrast. (Default is 75).
BRIGHT Switch
This control adjusts the brightness of the screen image. Press BRIGHT
switch and then VOLUME(DATA) switch to control the brightness.
(Default is 55).
COLOR Switch
This control adjusts the color intensity of the screen image. Press
COLOR switch and then VOLUME(DATA) switch to control the color
intensity. (Default is 50).
TINT Switch
With this switch, you can adjust the color to be close to natural.
For the best results, adjust the screen image so that skin tones appear
natural. Press TINT switch then VOLUME(DATA) switch to control the
color. (Default is 50).
This switch is not used when operated in PAL.
SHARP Switch
This control adjusts the sharpness of the screen image. Press SHARP
switch and then VOLUME(DATA) switch to control the sharpness.
(Default is 75).
e-11
CONTRAST
BRIGHT
COLOR
TINT
SHARP
