COLOR MONITOR User’s Guide Specifications
Specifications
System NTSC/PAL
CRT 21” diagonal, 0.7mm Stripe Pitch,
1.7 flat type 90° deflection
Horizontal Resolution More than 450 lines
Input Signal Video signal : 0.714Vp-p(Composite 1Vp-p)
Sync. signal : 0.286Vp-p
Sub Carrier 3.5795MHz ±400Hz(room temperature)
Frequency 4.433618MHz ±400Hz(room temperature)
Sync. Range
Horizontal ±500Hz
Frequency
Stability
Vertical ±4Hz
Frequency
Stability
High Voltage 25kV±1.5kV
Convergence less than 0.4mm (at the center of display area)
Power Consumption 75 Watts (maximum)
Operating Humidity Condition 0 to 90%
Operating Temperature Range 0 to 40°C
Power Control range or main section 90V~260V or
“indicated on the rear of the MONITOR set”
Dimensions (WxHxD) 490mm x 444mm x 482mm
Audio 2 Watts
Monitor will operate on NTSC or PAL video standard.
The monitor is self - adjusting to NTSC/PAL and voltage 100~240V.
e-9
