COLOR MONITOR User’s Guide Connections
Connections
e-13
Rear panel of MONITOR
IN
Video A
OUT IN
Video B
OUT IN
IN
Video C
OUT
OUT
ABC
VIDEO LINE AUDIO LINE
CCD Camera
VCR
S-VHS CCD Camera
S-VHS VCR
