Specifications
LCD Panel
Model number 917Sw
Driving system TFT Color LCD
Viewable Image Size 481mm diagoanl
Pixel pitch 0.2835mm(H) x 0.2835mm(V)
Video R, G, B Analog lnterface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 128 MHz
Resolution
Horizontal scan range
30 kHz - 83 kHz
Horizontal scan
Size(Maximum)
408.24mm
Vertical scan range 56 Hz - 75 Hz
Vertical scan
Size(Maximum)
255.15mm
Optimal preset
resolution
1440 x 900 (60 Hz)
Highest preset
resolution
1440 x 900 (60 Hz)
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, Positive
Power Source 100~240VAC, 47~63Hz
Power Consumption
Active < 37W
Standby < 1W
Physical
Characteristics
Connector Type 15-pin Mini D-Sub
Signal Cable Type Detachable
Dimensions &
Weight:
Height (with base)
439 mm
Width
358 mm
Depth
204 mm
Weight (monitor only)
3.8 kg
Weight (with
packaging)
4.7 kg
Environmental
Temperature:
Operating 0° to 50°
Non-Operating -20°to 60°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 80% (non-condensing)
Altitude:
Operating 0~ 3000m (0~ 10000 ft )
Non-Operating 0~ 5000m (0~ 15000 ft )
EPA ENERGY STAR ®
ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, AOC International (Europe) GmbH has
determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
