Apple CPX3 Projector User Manual



40
Item Description
MY BUTTON
This item is to assign one of the following function to MY BUTTON
1 and 2 on the remote control (
5).
Choose 1 or 2 on the MY BUTTON menu using the ◄/► button
rst. Then using the ▲/▼ buttons sets one of the following functions
to the chosen button.
• COMPUTER1: Sets port to COMPUTER IN1.
• COMPUTER2: Sets port to COMPUTER IN2.
• HDMI: Sets port to HDMI
• S-VIDEO: Sets port to S-VIDEO.
• VIDEO: Sets port to VIDEO.
INFORMATION: Displays a dialog of INPUT INFORMATION
(
42).
• AUTO KEYSTONE
: Performs automatic keystone distortion
correction (
31).
MY MEMORY: Loads one of adjustment data stored
(
25).
If you want to keep the current adjustment, please press the ◄
button to quit. Otherwise the current adjusted condition will be lost
by loading a data.
• PICTURE MODE: Changes the PICTURE MODE (
21).
• FILTER RESET:
Displays the lter time reset conrmation dialogue
(
39).
• AV MUTE: Turns the picture and audio on/off.
TEMPLATE: Makes the template pattern selected to the
TEMPLATE item (
37) appear or disappear.
MY SOURCE
Using ▲/▼ buttons selects the picture input port to be selected with
pressing the MY SOURCE/DOC.CAMERA button on the remote control.
Select the picture input that is connected with a document camera.
SERVICE
Selecting this item displays the SERVICE menu.
Select an item using the ▲/▼ buttons, and press the ► button or
the ENTER button to execute the item.
FAN SPEED
ó
AUTO ADJUST
ó
GHOST
ó
FILTER MESSAGE
ó
KEY LOCK
FACTORY RESET
ó
I NFORMATION
ó
REMOTE FREQ.
FANSPEED
Using the ▲/▼ buttons switches the rotation speed
of the cooling fans. The HIGH is the mode for use at
highlands etc. Note that the projector is noisier when
the HIGH is selected.
HIGH
ó
NORMAL
OPTION Menu (continued)
OPTION Menu
(continued on next page)
When the current adjustment
is not saved to memory a
dialog is displayed.
When no data is saved
in memory, a dialog is
displayed.
COMPUTER 1
ð
COMPUTER 2
(COMPUTER IN1) (COMPUTER IN2)
VIDEO
S-VIDEO
HDMI
