A O M - 7 6 9 4 A O M - 7 6 9 4
Backup (Rear) Camera
Rear-mounted cameras used for monitoring while backing up must be
connected to the CA1 input. Trigger#1 must be connected to the reverse gear light
circuit in the vehicle.
There are two camera options for rear camera installations: standard and tilt.
Tilt cameras and cables will connect directly to the 5-pin CA1 input. If a
standard(non-tilt) camera is installed as the rear camera, a 5-pin to 4-pin adapter
harness (included) must be used.
If side monitoring cameras are installed, they should be connected to either CA2 or
CA3 inputs. Triggers 2 and 3 should be connected to the vehicle's turn signal circuits.
Navigation
If a navigation computer is installed using the Component input, select the
Navigation setting from the Advanced menu for Source 4. Connect the Red, Green,
Blue and Brown RCA connectors from the AOM-7694 to the Navigation unit. Adapter
harness (1126810) is requir d to convert from the 4-pin camera connector to RCA
connectors and must be connected to Camera 4 input. Ues the R d RCA connector
from the harness to connect to the Navigation unit's audio output.
e
e
If a navigation computer is installed using the Composite input, select the A/V
setting from the Advanced menu for Source 4. Adapter harness (1126810) is required
to convert from the 4-pin camera connector to RCA connectors. Use the Yellow RCA
connector to the Navigation unit's composite Video output and the Red RCA
connector to connect to the Navigation unit's audio output.
Note: If connecting a Camera to the Camera 4 input, the Advanced Menu setting for
Source A/V 4 must be set to A/V.
A remote control repeater connection (1/8 jack) is included to allow control of the
navigation computer through the sensor on the front of the AOM-7694 monitor.
External (Additional) Monitors
An RCA video output is included and intended for connection to an external monitor
(i.e.bedroom TV).
Side Camera
Channel Selection On Trigger
The normal (default) operation is "OFF". To turn this feature on go to the Advanced
Menu and select "ON". When "OFF", the Camera selection button will not function
when a trigger wire is active. When "ON", the user can manually override
the triggered camera by using the Camera selection button.
