Typical System
Connection
A O M - 7 6 9 4 A O M - 7 6 9 4
VIDEO OUT
MALE
FEMALE
1
2 34
5
678
AOM-7694
MONITOR
MOLD-OVER
STRAIN RELIEF
YELLOW FEMALE
RCA CONNECTOR
(VIDEO OUT)
1/8" STEREO JACK
(3-WIRE)
(IR COMMAND REPEAT)
CHANNEL1
5-PIN FEMALE CONNECTOR
(S-VIDEO TYPE)
CHANNEL2~4
4-PIN ASA FEMALE
CAMERA CONNECTOR
(3-VIDEO TYPE)
TO NAVIGATION
BLUE
BROWN CHANNEL 2 TRIGGER
GREEN CHANNEL 3 TRIGGER
RED
WHITE
ORANGE CHANNEL 4 TRIGGER
BLACK GROUND
YELLOW 2-WAY SPLIT TRIGGER
CHANNEL 1 TRIGGER
POWER IN DC (10 TO 32V)
AUDIO/MUTE (AUDIO ON/OFF)
- OPTION -
For standard
ASA 4 pin
camera
in CHANNEL 1
31100014 CABLE
DETAIL-A
CAMERA4
RED : R Signal Input
GREEN : G Signal Input
BLUE : B Signal Input
BROWN : H,V Sync Signal
RED GRN BLU BRO
A
