ASUS A7N266 User’s Manual 29
3. HARDWARE SETUP
Expansion Cards
3. H/W SETUP
Interrupt Request Table for this Motherboard
INT-A INT-B INT-C INT-D INT-E
PCI slot 1 shared ————
PCI slot 2 ———shared —
PCI slot 3 ——used ——
PCI slot 4 — shared ———
PCI slot 5 shared ————
AGP ————used
ACR slot shared ————
Audio controller — shared ———
USB controller ———shared —
3.7.3 Advanced Communication Riser (ACR) Slot
This motherboard has an Advanced Communication Riser (ACR) slot for
communications and audio subsystems. The slot supports modem, audio, LAN, and
Home Phoneline Networking Alliance (HPNA) or Home Networking cards. This
ACR slot is backward compatible with ISA-side AMR cards only.
A7N266
010101
®
A7N266 Advanced
Communication Riser (ACR)
IMPORTANT: Only the ASUS ACR-A6CH Audio Communications Riser card is
recommended for use with this motherboard in the ACR slot. It is impossible to
install another card in the adjacent PCI slot since they are using the same space.
