4-22
Chapter 4: BIOS セットアップ
4.4.2 LAN Cable Status
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup
Defaults ESC: Exit →←: Select Menu Enter: Select Sub-menu
F10: Save and Exit
Select Menu
Item Specic Help
Enable or Disable LAN
cable check during POST.
AI Net2
POST Check LAN Cable [Disabled]
POST Check LAN2 Cable [Disabled]
Pair Status Length
LAN1(1-2) Open N/A
LAN1(3-4) Open N/A
LAN1(5-6) Open N/A
LAN1(7-8) Open N/A
LAN2(1-2) Open N/A
LAN2(3-4) Open N/A
LAN2(5-6) Open N/A
LAN2(7-8) Open N/A
Phoenix-Award BIOS CMOS Setup Utility
Advanced
POST Check LAN Cable [Disabled]
POST Check LAN2 Cable [Disabled]
POST 中に LAN/LAN2 ケーブルをチェックします。
設定オプション： [Disabled] [Enabled]
CPUtoNBHTVoltage[1.200V]
CPU to Northbridge HT Voltage を設定します。
設定オプション：[1.200V] [1.225V] [1.250V] ~ [1.500V]
NBtoSBHTVoltage[Auto]
NB to SB HT Voltage を設定します。
設定オプション：[+1.300V] [+1.325V] [+1.350V] ~ [+1.500V] [Auto]
NBCore/PCI-EVoltage[Auto]
NB Core/PCI-E Voltage を設定します。
設定オプション：[+1.200V] [+1.250V] [+1.300V] [+1.350V] [+1.400V] [Auto]
SBCore/PCI-EVoltage[Auto]
Southbridge core/PCI Express Voltage を設定します。
設定オプション：[+1.500V] [+1.525V] [+1.550V] ~ [+1.700V] [+1.750V] [Auto]
SBStandbyCoreVoltage[+1.50V]
Southbridge +1.5V Standby Voltage を設定します。
設定オプション：[+1.50V] [+1.60V] [+1.70V]
