2-8 ASUS M2N68-AM SE2
The following item appears only when the Memory Clock Mode item is set to [Manual].
Memclock Value [200MHz]
Allows you to set the memory clock value.
Conguration options: [200MHz] [266MHz] [333MHz] [400MHz]
The following sub-items appear only when you set the DRAM Timing Mode item to
[DCT 0].
CAS Latency (CL) [Auto]
Conguration options: [Auto] [3 CLK] ~ [6 CLK] [7 CLK DH_Only]
TRCD [Auto]
Conguration options: [Auto] [3 CLK] ~ [6 CLK]
TRP [Auto]
Conguration options: [3 CLK] ~ [6 CLK] [Auto]~ [6 CLK] [Auto]
tRTP [Auto]
Conguration options: [Auto] [2-4 CLK] [3-5 CLK]
TRAS [Auto]
Conguration options: [Auto] [5 CLK] ~ [18 CLK]
TRC [Auto]
Conguration options: [Auto]
tWR [Auto]
Conguration options: [Auto] [3 CLK] ~ [6 CLK]
TRRD [Auto]
Conguration options: [Auto] [2 CLK] ~ [5 CLK]
tRWTTO [Auto]
Conguration options: [Auto] [2 CLK] ~ [9 CLK]
tWRRD [Auto]
Conguration options: [Auto] [0 CLK] ~ [3 CLK]
tWTR [Auto]
Conguration options: [Auto] [1 CLK] [2 CLK] [3 CLK][Auto] [1 CLK] [2 CLK] [3 CLK]
tWRWR [Auto]
Conguration options: [Auto] [1 CLK] [2 CLK] [3 CLK]
Processor Frequency Multiplier [Auto]
Allows you to select the processor frequency. Conguration options: [Auto] [x4.0 800MHz]
[x5.0 1000MHz] [x6.0 1200MHz] [x7.0 1400MHz] [x8.0 1600MHz] [x9.0 1800MHz]
Processor Voltage [Standard]
Allows you to set the processor voltage. Conguration options: [Power Saving Mode]
[Standard] [+50mv] [+100mv]
Memory Clock Mode [Auto]
Allows you to select the memory clock mode. Conguration options: [Auto] [Manual]
DRAM Timing Mode [Auto]
Allows you to set the DRAM timing mode. Conguration options: [Auto] [DCT 0]
