Chapter 4: BIOS setupChapter 4: BIOS setup
Chapter 4: BIOS setupChapter 4: BIOS setup
Chapter 4: BIOS setup
DRAM Frequency [Auto]DRAM Frequency [Auto]
DRAM Frequency [Auto]DRAM Frequency [Auto]
DRAM Frequency [Auto]
Allows you to set the DDR operating frequency.
Configuration options: [Auto] [400 MHz] [533 MHz] [600 MHz]
Selecting a DRAM frequency that is not supported by your DIMM module
may cause the system to become unstable! If this happens, revert to
the default setting. See page 2-14 for qualified DDR2 DIMMs.
Performance Mode [Auto]Performance Mode [Auto]
Performance Mode [Auto]Performance Mode [Auto]
Performance Mode [Auto]
Allows enhanced system performance. Setting to [Turbo] may cause the
system to become unstable. If this happens, revert to the default setting
[Auto]. Configuration options: [Auto] [Standard] [Turbo]
Overclock Options [Overclock 5%]Overclock Options [Overclock 5%]
Overclock Options [Overclock 5%]Overclock Options [Overclock 5%]
Overclock Options [Overclock 5%]
Allows you to set the oveclocking options. Configuration options:
[Overclock 5%] [Overclock 10%] [Overclock 20%] [Overclock 30%]
[FSB888/DDR2-667] [FSB900/DDR2-600] [FSB950/DDR2-633]
[FSB1000/DDR2-667] [FSB1066/DDR2-533] [FSB1066/DDR2-710]
The following item appears only when the AI Overclocking item is set to
[Overclock Profile].
The following item appears only when the AI Overclocking item is set to
[AI N.O.S.].
NOS Mode [Auto]NOS Mode [Auto]
NOS Mode [Auto]NOS Mode [Auto]
NOS Mode [Auto]
Sets the Non-Delay Overclocking System mode. Select either of the
following configuration options:
AutoAuto
AutoAuto
Auto - loads the optimum sensitivity and overclocking percentage setting.
Standard Standard
Standard Standard
Standard - activates overclocking on a threshold between light and heavy
CPU loading.
Sensitive Sensitive
Sensitive Sensitive
Sensitive - activates overclocking on a light CPU loading.
Heavy LoadHeavy Load
Heavy LoadHeavy Load
Heavy Load - activates overclocking on a heavy CPU loading.
