2-2 Chapter2:Setup
2.2 Adjusting the monitor
• Foroptimalviewing,werecommendthatyoulookatthefullfaceofthe
monitor,thenadjustthemonitortotheanglethatismostcomfortableforyou.
• Holdthestandtopreventthemonitorfromfallingwhenyouchangeitsangle.
• Youcanadjustthemonitor’sanglefrom+20˚to-5˚anditallows60˚swivel
adjustmentfromeitherleftorright.Youcanalsoadjustthemonitor’sheight
within+/-10cm.
10cm
+20° ~ -5°
60°
0°
60°
Pivoting the monitor
1. Liftthemonitortothehighestposition.
2. Tiltthemonitortoitsmaximumangle.
3. Pivotthemonitorclockwisetotheangleyouneed.
+20° ~ -5°
Itisnormalthatthemonitorslightlyshakeswhileyouadjusttheviewingangle.
(Tilt) (Swivel) (Heightadjustment)
