ASUS P/I-P55TVP4 User’s Manual 7
III. INSTALLATION
Jumper Settings
1. Onboard Multi-I/O Selection (JP9)
You can selectively disable each onboard Multi-I/O item (floppy, serial, paral-
lel, and IrDA) through Chipset Features Setup of BIOS SOFTWARE or dis-
able all Multi-I/O items at once with the following jumper in order to use your
own Multi-I/O card.
Multi-I/O JP9
Enable [1-2] (Default)
Disable [2-3]
Multi I/O Setting (Enable / Disable)
1
2
3
JP9
Enable (Default) Disabled
1
2
3
JP9
2. Flash ROM Boot Block Programming (JP10)
This sets the operation mode of the boot block area of the Programmable Flash
ROM to allow programming in the Enabled position. This is required only if
prompted by the Flash Memory Writer Utility as shown in BIOS SOFTWARE.
Programming JP10
Disabled [1-2] (Default)
Enabled [2-3]
Boot Block Programming (Disable / Enable)
Disabled / Protected
(Default)
Enabled
1
2
3
JP10
1
2
3
JP10
III. INSTALLATION
(Jumpers)
