AXIS Q7424-R Installation Guide Page 5
ENGLISH
AXIS Q7424-R Video Encoder
Installation Guide
This installation guide provides instructions for installing the AXIS Q7424-R video encoder on your
network. For all other aspects of using the product, please see the product’s User Manual on
www.axis.com
Installation steps
Follow these steps to install AXIS Q7424-R on your local network (LAN):
1. Check the package contents against the list below.
2. Hardware overview. See page 6.
3. Install the hardware. See page 7.
4. Assign an IP address. See page 8.
5. Set the password. See page 11.
Package contents
Item Models/variants/notes
Axis video encoder model AXIS Q7424-R
Mounting kit • 4 Surface protection pads
• Terminal block connectors (I/O: 6-pin connector, RS-485/RS-
422: 2 x 2-pin connector, Power: 3-pin connector, Audio: 4-pin
connector)
• Allen key (hex key) for tamper-proof SD-lid screw
CD AXIS Network Video Product CD, including installation tools and other
software
Printed materials AXIS Q7424-R Installation Guide (this document)
Axis Warranty Document
Optional accessories DIN Rail Clip
Important!
This product must be used in
compliance with local laws and
regulations.
