13
Chapter 2 Scan/Email Operations
6
Insert a PCMCIA/PC Card Adapter
with a memory card.
① Push on the slot cover to open it.
② Insert a PCMCIA/PC card into the PCMCIA/
PC Card slot as illustrated. (Label side up)
7
Select “PC Card”.
zOnly one storage device can be selected at
a time. When the "PC Card" is selected as a
storage device, the scanned image cannot
be saved to the SD Memory Card or Hard
Disk Drive at the same time.
8
Press the Start key.
The scanned image is saved into the
PCMCIA/PC Card.
The scanned data is saved on the following
directory of the memory card.
zDirectory:
\PRIVATE\MEIGROUP\PCC\DI\IMAGE
zWhen scanning from the Platen Glass, place
the next original, and then follow the
instructions described on the touch panel
display.
9
Push the Eject button on the right side
of PCMCIA/PC Card slot, and then
remove the PCMCIA/PC Card
Adapter.
zDo not remove the PCMCIA/PC Card while
the Access Indicator is flashing.
10
Close the Slot Cover.
zWhen canceling the operation, press the Stop key
on the Control Panel, and then select “Yes” on the
Touch Panel Display.
Eject button
