Brother DCP-7065DN All in One Printer User Manual



Routine maintenance
33
A
g Put the new toner cartridge firmly into
the drum unit until you hear it lock into
place. If you put it in properly, the green
lock lever will lift automatically.
h Clean the primary corona wire inside the
drum unit by gently sliding the green tab
from left to right and right to left several
times.
Note
Be sure to return the tab to the home
position (a) (1). If you do not, printed
pages may have a vertical stripe.
i Put the drum unit and toner cartridge
assembly back into the machine. Close
the front cover.
1
