Installing the Cisco ONS 15600 OC48/STM16 LR/LH 16 Port 1550 Card
78-15182-01
OC48/STM16 LR/LH 16 Port 1550 Card
OC48/STM16 LR/LH 16 Port 1550 Card-Level Indicators
Table 2 describes the functions of the card-level LEDs on the OC48/STM16 LR/LH 16 Port 1550 card.
OC48/STM16 LR/LH 16 Port 1550 Network-Level Indicators
Table 3 describes the functions of the network-level LEDs on the OC48/STM16 LR/LH card.
Warning
Invisible laser radiation may be emitted from the end of the unterminated fiber cable or connector. Do
not stare into the beam or view directly with optical instruments. Viewing the laser output with
certain optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance
of 100 mmmay pose an eye hazard.Use of controls oradjustments or performanceof procedures other
than those specified may result in hazardous radiation exposure.
Table 2 OC48/STM16 LR/LH 16 Port 1550 Card-Level Indicators
Indicators Color Description
STAT LED
Red Indicates a hardware fault; this LED is off during normal operation.
Replace the card if the STAT LED persists. During diagnostics, the LED
will flash quickly during initialization and flash slowly during
configuration synchronization.
SRV LED
Green Indicates the service mode of the card. Green indicates the card isin use;
off indicates when the card can be removed for service.
LASER ON
Green The green LASER ONLED indicates that at leastone of the card’s lasers
is active.
Table 3 OC48/STM16 LR/LH 16 Port 1550 Network-Level Indicators
Indicators Color Description
SD LED
Blue The blue SD LED indicates a signal degrade or condition such as a low
level signal on at least one of the card’s ports.
SF LED
Red The red SF LED indicates a signal failure or condition such as LOS,
LOF, or high BERs on at least one of the card’s ports. The red SF LED
also illuminates when the transmit and receive fibers are incorrectly
connected. When the fibers are properly connected, the LED turns off.
