❚❚❚ Main Features ❚❚❚
<High-speed, high-quality printing>
This printer can be used for high-speed high-quality printing thanks to its direct thermal method
and thermal transfer method that use a line thermal printhead together with its 32 bit RISC CPU
and its 'history control IC'.
<Easy operation>
It is easy to change the printer’s settings on the operation panel, thanks to its unique and
simple VuePrint menu system.
•Its high-lift printhead and mechanism means that media and ribbon can be loaded with ease
and it is constructed for easy thermal printhead cleaning, etc.
Media width adjustment, media thickness adjustment, and media sensor adjustment can all be
made easily by the user using the colour-coded operator controls.
<Dual Programming Language>
This printer contains both the Datamax
®
and Zebra
®
emulations and will automatically detect
the language using the Cross-Emulation
TM
feature.
<Interface>
An industry standard RS232 serial port and USB1.1 port are standard equipment, for quick data
transfer and printing.
<Optional interface>
Additional connectivity is available with an optional internally-housed IEEE1284 parallel port,
an Ethernet interface and a wireless LAN print server.
<Optional auto-cutter / peeler unit>
The auto-cutter and peeler units are designed so that they can be installed easily.
<Adjustable sensors>
The adjustable media sensors - which allow the sensors to be positioned in different locations
across the media - are standard features making the printer ideal for use with special media.
<Installation>
The interface, power switch etc. are installed towards the back and the top cover opens and
closes vertically so that the sides of the printer are not restricted.
INTRODUCTION
Thank you for purchasing a Citizen CL-series label printer offering high performance thermal transfer printing
on media up to 4.1 inches wide.
