Setup
10
Confirmation of Carton Contents
Note: The empty carton and packing materials should be stored for future
shipping of the printer.
When removing the CL-S700R from the box, there is the extra
cardboard “sling” to make lifting easier.
Removing the Packing Material
The printer is shipped with adhesive tape in place to hold the top cover
closed. Simply remove the two pieces of tape on either side of the top cover.
Then simply open the cover by lifting up and tipping it backwards.
There is another strip of adhesive tape that must be removed which holds
the mechanism closed for shipping. Remove the tape and attached paper by
carefully peeling from the plastic case.
Retain the tape should you need to transport the printer again. A further
piece of packing paper is inside the mechanism and you can remove this
when the head is opened as explained later in the manual.
CD-ROM
Quick-start guide
Media holder barMedia holder guide
Head cleaner
Paper core
(for ribbon)
Sample ribbonRibbon holder
Test label media Power cord
Printer
[Model CL-S700/CL-S703]
CL-S700 Series
Thermal Transfer Barcode & Lab
el Printer
U
S
E
R
'S
M
A
N
U
A
L
CL-S700
CL-S703
CL-S700R
Check that the following accessories are included with the printer
in the carton.
