E-18
Connections with the Personal Computer
Please check the matters described below when the image of the personal computer is not projected or when there is
projection but the image is not correct.
● The image is not projected
When the external output signal from the personal computer is not input to the iP-25E, "No signal being input" is displayed on the
display screen of the iP-25E. Should this occur, please check the following matters.
1 Try restarting the personal computer.
When the iP-25E is connected after the personal computer has been started, the connection of the iP-25E might not be
recognized by the personal computer. When the iP-25E has not been recognized, the external output signal from the personal
computer will not be output and there will not be an image to project.
2 Check the functions of the personal computer.
Depending on the notebook computer, some computers will require an operation to output a signal from the external output
connector. If this operation is not performed, the external output signal from the notebook computer will not be output.
Please see the instruction manual of the notebook computer you are using and perform the operation that will output the signal
from the external output connector.
(Operation Example)
IBM PC/AT and DOS/V computers:
Press the [Fn] key + "any one of the [F1] to [F12] keys (noting that the operation will differ depending on the model)"
PC98 notebook computers later than the Nr Series (with the exception of the PC-98NX):
Press the "Suspend Resume" switch.
Correspondence List for Connection Problems with the Personal
When the Image of the Personal Computer Screen Is Not Projected
●
The screen of the personal computer is correct, but the image is not projected properly
Please check the functions of the personal computer.
Even though the LCD screen of the notebook computer is properly displayed, the projected image might not be projected
properly. Due to restrictions of the notebook computer there will rarely be instances in which the setting of a simultaneous
display (i.e., simultaneous output of the external output signal while displaying the screen of the personal computer) will result
in a signal that greatly deviates from the range supported by the iP-25E and proper projection will not be possible.
Should this occur, a proper image will not be obtained even when adjustments are made with the iP-25E.
In some instances, the personal computer screen will be properly projected by the iP-25E when the simultaneous display is
cancelled and an operation is performed to output only the external output signal. Please see the instruction manual of the
notebook computer you are using for details.
Manufacturer External Output Switching Method Manufacturer External Output Switching Method
IBM Fn+f7 DELL Fn+f8
NEC Parallel output Toshiba Fn+f5
Switching from the Task Bar
Panasonic Fn+f3
Fn+f3 Fujitsu Fn+f10
COMPAQ Fn+f4 Mitsubishi Fn+f5
Sharp Fn+f5 Apple Control panel
SONY Fn+f7 → monitor display switching
* This table indicates the results of an independent investigation by us of representative computers made
by various manufacturers; it does not include all of the connections.
* Company names and product names mentioned are the trade marks or registered trademarks of the
respective companies.
