QuickSpecs
ProLiant BL20p and p-Class system
DA-11411 Canada — Version 1 — August 26, 2002
18
Technical Specifications
Dimensions Height
10.405 in/26.43 cm
Operating and Performance
Specifications for RJ-45 Patch Panel
Width
1.535 in/3.899 cm
Depth
27.697 in/70.35 cm
Capability IEEE 802.2, 802.3, 802.3u
Network transfer rate
10 Base-T (half-duplex) 10 Mbps
10 Base-T (full-duplex) 20 Mbps
100 Base-TX (half-duplex) 100 Mbps
100 Base-TX (full-duplex) 200 Mbps
1000 Base-TX (full-duplex) 1000 Mbps
Connector RJ-45
Cable support 10 Base-TX Categories 3, 4, or 5 UTP (2 or 4 pair); up to
328 ft/100 m
100 Base-TX Category 5 UTP (2 pair); up to 328 ft/100 m
1000 Base-TX Category 5E (4 pair); up to 328 ft/100 m
Power requirements
200 mA at +5V DC; 500 mA at -48V
Temperature range Operating 50° to 95° F/10° to 35° C
Non-operating
-22° to 140° F/-30° to 60° C
Operating
20% to 80%
Relative humidity (non-
condensing)
Non-operating
5% to 95%
Operating
82.4° F/28° C
Wet bulb temperature
Non-operating
101.7° F/38.7° C
Note: Operating temperature has an altitude derating of 34° F/1° C per 1,000 ft/304.8 m. No direct sunlight.
Upper operating limit is 10,000 ft/3,048 m or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft/ 9,144
m or 30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of
113° F/45° C. Altitude maximum for storage is 70 KPa.
