APPENDIX: CT1702 Display Modes (Analog)
48
APPENDIX: CT1702 Display Modes (Analog)
For the display modes listed below, the screen image has been optimized
during production.
Preset Timing Modes (Analog)
Our Monitor is not supported outside of the display modes
listed above.
Mode
Display
Mode
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Standard
Type
VGA
640 x 350 31.5KHz 70Hz IBM®
720 x 400 31.5KHz 70Hz IBM®
640 x 480 31.5KHz 60Hz Industry Standard
640 x 480 37.9KHz 72Hz VESA Standard
640 x 480 37.5KHz 75Hz VESA Standard
640 x 480 43.3KHz 85Hz VESA Standard
SVGA
800 x 600 35.2KHz 56Hz VESA Guidelines
800 x 600 37.9KHz 60Hz VESA Guidelines
800 x 600 48.0KHz 72Hz VESA Standard
800 x 600 46.9KHz 75Hz VESA Standard
800 x 600 53.7KHz 85Hz VESA Standard
XGA
1024 x 768 48.4KHz 60Hz VESA Guidelines
1024 x 768 56.5KHz 70Hz VESA Standard
1024 x 768 60.0KHz 75Hz VESA Standard
1024 x 768 68.7KHz 85Hz VESA Standard
SXGA
1280 x 1024 64.0KHz 60Hz VESA Standard
1280 x 1024 80.0KHz 75Hz VESA Standard
