tilt touchpanels
INTERFACE MODULES AND CABLES
TPS-CBL-S Siamese Cable for Isys
®
Tilt Touchpanels
Isys TPS-CBL-S “siamese” cables are designed for
use with Isys TPS-3000 and TPS-4000 tilt touchpanels.
Available in a variety of lengths, a TPS-CBL-S cable may
be used in place of the longer 15' cable provided with
the touchpanel, carrying Cresnet, video, and audio
signals between the touchpanel base and interface
module in a singular lightweight, flexible cable assembly.
AVAILABLE MODELS
TPS-CBL-S3
Length: 3 foot (0.9 meters)
TPS-CBL-S6
Length: 6 foot (1.8 meters)
TPS-CBL-S9
Length: 9 foot (2.7 meters)
SPECIFICATIONS
Connectors
(2) 10-pin RJ45 male, shielded
(2) 8-pin RJ45 male, shielded
Carries Cresnet data, 24 Volts DC power, ground, video, and
audio signals
55
TPS-CBL Cable for Isys
®
Tilt Touchpanels
Isys TPS-CBL cables are designed for use with Isys
TPS-3000 and TPS-4000 tilt touchpanels whenever
the touchpanel’s built-in microphone and speakers
are not being used. Available in a variety of lengths,
a TPS-CBL cable may be used in place of the longer
15' cable provided with the touchpanel, carrying
Cresnet and video signals between the touchpanel
base and interface module in a single lightweight,
flexible cable.
AVAILABLE MODELS
TPS-CBL-3
Length: 3 foot (0.9 meters)
TPS-CBL-6
Length: 6 foot (1.8 meters)
TPS-CBL-9
Length: 9 foot (2.7 meters)
SPECIFICATIONS
Connectors
(2) 10-pin RJ45 male, shielded
Carries Cresnet data, 24 Volts DC power, ground, and
video signals
