Top Products
KVM Switches
KVM User x System Configuration 1 x 16
Number of PCs per KVM Switch 16 PCs
Additional Features
Hot pluggable KVM switch allows you to add or
remove PC connections without powering down
the KVM switch
Keyboard 'Hot Key' Commands for switching
channels, banks, and OSD commands
Front handle folds down for lower rack-
protrusion profile
Cables & Connectors
Number of Connectors 16
Connector Type HD-15 (VGA standard)
Connector Gender Female (socket)
Connector Details
KVM set connector on KVM side is special 15-pin
connector that incorporates the keyboard and
mouse signals. There is only 1 connector per
channel on the KVM side.
Video/KVM
Connectors
Cabling Details
Using a GFA 16CBLxx cable, on the PC side
there is a regular complement of VGA, mouse,
and keyboard male connectors.
Power Chassis Power Input Connector NEMA standard male PC cord socket
Indicators, Switches, & Controls
On Screen Display (OSD) Control Functions
Brightness
Contrast
RGB color adjustments
Horizontal position
Vertical position
Horizontal size
Vertical size
Color balance
Color temperature adjustment
Video source selection
Select language for OSD controls
Position of OSD controls
Reset to factory defaults
Geometry (convex/concave sides)
Geometry (parallelogram)
Phase adjustment
Auto adjustment
Recall (last OSD setting)
LCD Display On/Off Switch Yes
OSD Controls OSD controls for menu navigation (3 buttons)
Brightness Via OSD controls
Front Panel
Controls
Contrast Via OSD controls
Rear Panel
Controls
Power On/Off Switch
1 on/off switch
Power On/Off LED indicates power on
System in Sleep Mode Shown by change in LED color
Channel Number Active channel shown by 16 LEDs
Indicators
Buzzer for Alarms Yes
CyberResearch
®
PC Accessories GFC 1716A
