Network Cables Supported
The connectors and network cables supported by the converter are listed in
the following table:
Connector Type of Network Network Cable Supported
RJ-45 100BASE-TX Cat 5 Twisted-Pair
Fiber SC 100BASE-FX 1300nm
62.5/125,50/125 µm
Multimode fiber
Table 1- 1
Features
The DFE-855 100BASE-TX to 100BASE-FX Fast Ethernet Converter
includes the following features:
•
•
•
•
•
•
•
•
•
•
Conforms to the IEEE 802.3u 100BASE-TX and 100BASE-FX
standards.
100 Mbps data transfer rate.
Auto detection, half / full duplex mode.
Supports transmission distances of up to 2 km (full-duplex).
One fiber optic SC connector and one RJ-45 connector. (Refer to
Appendix B: RJ-45 Pin Specifications.)
LED indicators allow for visual verification of power, linkage
and data received.
Operating temperature of 0 to 40 degrees Celsius.
Storage Temperature of 25 to 55 degrees Celsius
Humidity of 5 - 90% (non-condensing)
EMI Certification including CE, FCCA, VCCIA and C-Tick.
