Appendix A
Technical Specifications
General
Standards: IEEE 802.3u 100BASE-TX
IEEE 802.3u 100BASE-FX
Data
Transfer
Rate:
100Mbps (Half-duplex) Fast Ethernet:
200Mbps (Full-duplex)
Network
Cables:
Fast Ethernet: 2-pair UTP Cat. 5,
Unshield Twisted Pair (UTP )Cable
Fast Ethernet: 1300nm
62.5/125,50/125 µm
Multimode fiber cable
Number
of Ports:
One (1) 100BASE-TX Fast Ethernet port
One (1) 100BASE-FX Fase Ethernet port
Physical and Environmental
DC Inputs: DC 5V 1A (Power Adapter)
Power
Consumption:
3.5 watts maximum
Operating
Temperature:
32°F ~ 104F ° (0 °C ~ 40 ºC)
Storage
Temperature:
14°F ~ 158°F (-10°C ~ 70°C)
Humidity: 5% ~ 95% RH, non-condensing
Dimensions:
4.53 in. x 2.44 in. x 0.89 in.
(115 mm x 62 mm x 22.5 mm)
Weight 0.16 Kg.
EMI FCC Class A, CE Class A, C-Tick, VCCI Class A
Safety: CSA International
