Standard Timing Table
Standard Timing Table
TIMING NAME
FH (KHz)
FV (Hz)
SYNC
POLARITY
TOTAL
(DOT / LINE)
ACTIVE
(DOT / LINE)
SYNC
WIDTH
(DOT / LINE)
FRONT
PORCH
(DOT / LINE)
BACK
PORCH
(DOT / LINE)
PIXEL
FOREQ.(MHz)
640x350 31.469 + 800 640 96 16 48
VGA-350 70.087 – 449 350 2 37 60
25.175
640x400 31.469 – 800 640 96 16 48
VGA-GRAPH 70.087 + 449 400 2 12 35
25.175
640x480 31.469 – 800 640 96 16 48
VGA-480 59.94 – 525 480 2 10 33
25.175
640x480 35 – 864 640 64 64 96
APPLE MAC-480 66.67 – 525 480 3 3 39
30.24
640x480 37.861 – 832 640 40 16 120
VESA-480-72Hz 72.809 – 520 480 3 1 20
31.5
640x480 37.5 – 840 640 64 16 120
VESA-480-75Hz 75 – 500 480 3 1 16
31.5
720x350 31.47 + 900 720 108 18 54
70Hz 70.087 – 449 400 2 37 60
28.322
720x400 31.469 – 900 720 108 18 54
VGA-400-TEXT 70.087 + 449 400 2 12 35
28.322
832x624 49.725 – 1152 832 64 32 224
APPLE MAC-800 74.55 – 667 624 3 1 39
57.2832
800x600 35.156 + 1024 800 72 24 128
SVGA 56.25 + 625 600 2 1 22
36
800x600 37.879 + 1056 800 128 40 88
VESA-600-60Hz 60.317 + 628 600 4 1 23
40
800x600 48.077 + 1040 800 120 56 64
VESA-600-72Hz 72.188 + 666 600 6 37 23
50
800x600 46.875 + 1056 800 80 16 160
VESA-600-75Hz 75 + 625 600 3 1 21
49.5
848x480 31.02 + 1088 848 64 32 152
VESA 60 + 517 480 3 1 27
56.25
1024x768 48.363 – 1344 1024 136 24 160
XGA 60.004 – 806 768 6 3 29
65
1024x768 53.964 + 1328 1024 176 16 112
COMPAQ-XGA 66.132 + 816 768 4 8 36
71.664
1024x768 56.476 – 1328 1024 136 24 144
VESA-768-70Hz 70.069 – 806 768 6 3 29
75
1024x768 60.023 + 1312 1024 96 16 176
VESA-768-75Hz 75.029 + 800 768 3 1 28
78.75
1024x768 60.24 – 1328 1024 96 32 176
APPLE MAC-768 75.02 – 803 768 3 3 29
80
1152x864 54.054 + 1480 1152 96 40 192
(60Hz) 59.27 + 912 864 3 13 32
80
1152x864 63.851 + 1480 1152 96 32 200
(70Hz) 70.012 + 912 864 3 1 44
94.499
1152x864 67.5 + 1600 1152 128 64 256
(75Hz) 75 + 900 864 2 2 32
108
1152x870 68.68 – 1456 1152 128 32 144 100
If the selected timing is NOT included in table below, this LCD monitor will use the most suitable available timing.
(75Hz) 75.06 – 915 870 3 3 39
1280x720 44.772 – 1664 1280 128 64 192
(60Hz) 59.855 + 748 720 5 3 20
74.5
1280x960 60 + 1800 1280 112 96 312
(60Hz) 60 + 1000 960 3 1 36
108
1280x960 70 + 1800 1280 112 96 312
(70Hz) 70 + 1000 960 3 1 36
126
1280x960 75 + 1800 1280 112 96 312
(75Hz) 75 + 1000 960 3 1 36
135
1280x1024 64 + 1688 1280 112 48 248
VESA-1024-60Hz 60 + 1066 1024 3 1 38
108
1280x1024 80 + 1688 1280 144 16 248
VESA-1024-75Hz 75 + 1066 1024 3 1 38
135
1360x768 75 + 1792 1360 112 64 256
60Hz 75 + 795 768 6 3 18
85.5
1440x900 55.469 + 1600 1440 32 48 80
Red. BLKing 60Hz 59.901 – 926 900 6 3 17
88.75
1440x900 55.935 – 1904 1440 152 80 232
60Hz 59.887 + 934 900 6 3 25
106.5
1440x900 70.635 – 1936 1440 152 96 248
75Hz 74.984 + 942 900 6 3 33
136.75
1680x1050 64.674 + 1840 1680 32 48 80
Red. BLKing 60Hz 59.883 – 1080 1050 6 3 21
119
1680x1050 65.29 – 2240 1680 176 104 280
60Hz 59.954 + 1089 1050 6 3 30
146.25
1680x1050 82.306 – 2272 1680 176 120 296
75Hz 74.892 + 1099 1050 6 3 40
187
1600x1200 75 + 2160 1600 192 64 304
VESA-1200-60Hz 60 + 1250 1200 3 1 46
162
1600x1200 87.5 + 2160 1600 192 64 304
VESA-1200-70Hz 70 + 1250 1200 3 1 46
189
1600x1200 93.75 + 2160 1600 192 64 304
VESA-1200-75Hz 75 + 1250 1200 3 1 46
202.5
1920x1200 74.038 + 2080 1920 32 48 80
Red. BLKing 60Hz 59.95 – 1235 1200 6 3 26
154
1920x1200 74.566 – 2592 1920 200 136 336
60Hz 59.885 + 1245 1200 6 3 36
193.25
*** DVI signal can not support 1680X1050@75, 1600X1200@70, 1600X1200@75, 1920X1200@60 non reduce mode
Note: Mode 640x350, 640x400 and 720x400 will be locate on middle in the position and cannot be expanded to full
screen on vertical direction.
