label), or CUT and TAB cut for easy removal from the
backing tape.
LANGUAGE
• Press
to step through the operating languages
available on the Labelmaker. The SET UP display will
change accordingly .
• Press
to change to the selected language and
return to edit mode. The Labelmaker will retain the
chosen operating language until you change it again.
UNITS
• Press
to choose between UNITS of measure
INCHES or MM, as shown in the status bar.
PC LINK
• Press to select PC LINK mode when the
Labelmaker is connected to a PC – see the
instructions accompanying the software for details.
• The display will change to show
to confirm PC LINK mode selection. Note that the
Labelmaker will not respond to the keyboard in PC
LINK mode, with the exception of the
ESC
key.
• Press
ESC
to cancel PC LINK mode and return to
normal operation.
Cleaning
• Check and clean the print head and pinch roller
regularly.
Follow the instructions packed with the cleaning tool.
Moisten the cleaning tool with alcohol and clean the
pinch roller and print head as shown
D➊.
• After cleaning, store the tool in the lid
D➋ for future
use.
Troubleshooting
No display
• check machine is on
• check AC adaptor connected, plugged in and
switched on.
No printing or poor text
•
wrong cassette fitted for label to be
printed. See CASSETTE option in ‘SET UP’ menu.
•
ink cassette missing or lid open
•
label not removed from cutter area - remove
before printing next label
•
label tape run out – replace the cassette
•
ink tape run out – replace the cassette
•
printhead overheat safety cutout warning.
May occur if printing many labels with dense image.
Stops for 3 minutes for head to cool, then resumes
printing automatically.
• check correct tape and ribbon cassettes installed
• check tape cassette installed correctly
• clean the print head.
Poor cutter performance
•
cutter jammed – clear jam and clean cutter
• clean the cutter blade regularly.
Poor tab cuts
• replace tab cutter blade
E➊ – remove the single
screw in the top of the cutter block, then pull it
straight up to remove.
WARNING – the blade is extremely sharp!
No response to print key
•
in the display indicates a printer jam. Press any
key to return to normal display. Open the cassette
compartment and free the jam.
No success?
• Call the customer service telephone number in your
country – see the warranty booklet.
In the USA, call 800-645-6051
In Canada, call (905) 670-2222
