1-4 Elo Entuitive Touchmonitor User Guide
Specifications
Sensor SecuGen FOR
Image Capture Speed 600ms / frame
Image Transfer Speed 500Byte / ms
Pixel Resolution 356 x 292
USB Signaling Type Full Speed Type
Theory of Operation
The USB host initiates communication with the FDU01 using operation commands (Sensor LED On,
Fingerprint Capture Start and Stop). Fingerprint data are then captured by the CMOS sensor at a total
image size of 356 x 292 with 8-bit gray level. The image frame transfer speed is 500 bytes/ms. It
takes about 600 milliseconds to send one frame of image data over USB protocols.
FDU01 uses the SecuGen FOR (Fingerprint Optic Reader).
Sensor Specifications
Sensor CMOS Image Sensor
Resolution 500dpi
Verifying Time < 1sec
Image Capture Error Rate < 0.1%
Life Time Typically 40,000Hrs
Credit Card Reader
There is a serial credit card reader and a USB credit card reader.
The USB version is available in HID and Keyboard emulation versions. The reader reads all three
stripes on a standard credit card or drivers license. A green LED provides the operator with continu-
ous status of the reader operations.
Reference Standards-Conform to International Standards Organization, American National
applicable standards Standards Institute, California Drivers License, American
Association of Motor Vehicle Administrators
Message Format ACCII
Card Speed 3 to 50 IPS
MTBF Electronics 125,000 hrs; Head 1,000,000 passes
