Product Data Document
420DS-4c
July 19, 2007 - Page 11
Bristol
®
ControlWave
®
LP
Emerson Process Management
Remote Automation Solutions
Watertown, CT 06795 USA T 1 (860) 945-2200
Mississauga, ON 06795 Canada T 1 (905) 362-0880
Worcester WR3 8YB UK T 44 (1) 905-856950
Website: www.EmersonProcess.com/Remote
© 2007 Remote Automation Solutions, division of Emerson Process Management. All rights reserved.
Bristol, Inc., Bristol Babcock Ltd, Bristol Canada, BBI SA de CV and the Flow Computer Division , are wholly owned subsidiaries of Emerson Electric Co. doing business as Remote Auto-
mation Solutions (“RAS”), a division of Emerson Process Management. FloBoss, ROCLINK, Bristol, Bristol Babcock, ControlWave, TeleFlow and Helicoid are trademarks of RAS. AMS,
PlantWeb and the PlantWeb logo are marks of Emerson Electric Co. The Emerson logo is a trademark and service mark of the Emerson Electric Co. All other marks are property of their
respective owners.
The contents of this publication are presented for informational purposes only. While every effort has been made to ensure informational accuracy, they are not to be construed as war-
ranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. RAS reserves the right to modify or improve the designs or
specications of such products at any time without notice. All sales are governed by RAS’ terms and conditions which are available upon request. RAS does not assume responsibility for
the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of any RAS product remains solely with the purchaser and end-user.
The security system provides for up to sixty-four
access rights to read and write data values and les
via FTP, access and congure historical and audit
data information, edit conguration, run internal
diagnostics, read and reset system status. It further
allows the programming software to read, write and
download the ControlWave.
The Secure Data Advantage
ControlWave sets a new standard for providing in-
telligent control at the point where control is needed.
Whether you need control on the plant oor or at a
remote site in the “middle of nowhere” ControlWave
is the solution for control, communication and
secure data to help you make the right operating
decisions.
ControlWave was designed to provide the optimum
level of data security using a distributed database
architecture. All data including time & date stamped
alarms, alarm limits, and historical data are stored
locally in each industrially rugged ControlWave,
thereby distributing your data integrity risk. To
further ensure that the data is always current and
historically accurate, the historical data is stored
in non-volatile ash memory within ControlWave.
Historical data is even maintained during and after
program downloading.
When historical data is collected from ControlWave,
it is converted and appended to .CSV and/or ODBC
compliant databases but does not destroy the origi-
nal historical data stored in ControlWave. Thus, a
exible and secure historical data system is clearly
recognized as a benet to virtually every industrial
application.
The Bridge Between Systems
Continuing our tradition of introducing innovative
new solutions while maintaining compatibility with
existing systems, Emerson again provides a migra-
tion path for existing customers by bridging the new
ControlWave system with Network 3000 systems
already in place. The network bridge is enabled
by employing the open architecture technologies
afforded by TCP/IP and OPC in both networks.
TCP/IP allows seamless Ethernet connectivity to
both networks as well as the corporate Intranet so
both ControlWave and Network 3000 controllers
can reside and communicate on the same LAN.
Emerson’s Bristol OpenBSI OPC Server facilitates
the merging of the two networks for technical, engi-
neering and operator data access. The data source,
conguration and path are completely transparent to
the OPC client. Real-time data can also be passed
between the two communication networks making
this a total Plant Automation Management Solution.
