Product Data Document
420DS-1k
July 16, 2007 - Page 1
Website: www.EmersonProcess.com/Remote
Remote Automation Solutions
Bristol
®
ControlWave
®
PAC
Process Automation Controller
Bristol® ControlWave® PAC, from Emerson Pro-
cess Management, is a highly adaptable, high
performance Process Automation Controller with
exceptional networking capability to provide a
complete Process Automation Management Solu-
tion. Designed with a great emphasis on scalability
and modularity, ControlWave can be congured to
maximize the performance of a wide range of con-
trol systems, from small or mid-size applications to
large ones. Additionally, due to its small form factor
and rugged industrial design, ControlWave offers an
outstanding ability to match the requirements of the
most demanding process plant and SCADA system
environments. Above all, Emerson has developed
this innovative controller to provide cost-effective
solutions by minimizing the time required for instal-
lation and conguration.
Through this new open architecture, ControlWave
provides an ideal hybrid union of PLC, RTU and
DCS without compromising the unique features
and capabilities of each product. Consequently, the
ControlWave Process Automation Controller not
only introduces the great possibilities of an open
architecture for emerging communication standards,
but it also provides a simple solution for existing
networks. From its conception, ControlWave was in-
tended as a very exible system capable of satisfy-
ing the requirements of local, expanded, remote and
distributed I/O combinations. It is widely accepted
as a scalable platform because it can be used for
small applications using a single rack, but it can
also be expanded to large applications spanning an
entire plant.
Hardware Features
586 based processor provides unparalleled
performance
Up to three 100/10 MB Ethernet ports
Ethernet remote I/O
Up to four serial communication ports
2, 4, and 8 I/O slot panel mount chassis, panel
or 19” rack mount on 8 slot chassis
Single and double density I/O modules
Hot Swap I/O replacement
Security key-lock to prevent unauthorized
access
Internal loop power for I/O simplies installation
AOs maintain last/preset value on CPU
Watchdog
DOs maintain last or zero value on CPU
Watchdog
Wide temperature range (-40 to +70ºC)
Class I, Div. 2 hazardous location and CE
approval
Open, industry standards for programming,
conguration and communication
•
•
•
•
•
•
•
•
•
•
•
•
•
•
