Product Data Document
420DS-1k
July 16, 2007 - Page 19
Bristol
®
ControlWave
®
PAC
Remote Automation Solutions
Website: www.EmersonProcess.com/Remote
ControlWave Base Unit
DESCRIPTION PART NO.
ControlWave main and I/O Expansion rack Chassis (Holds PSSM, CPU and 2, 4, or 8 I/O modules)
Select either the ControlWave CPU or I/O Expansion rack CPU.
0 I/O slot chassis Panel mount 396463-01-0
2 I/O slot chassis Panel mount or 19” rackmount 396356-03-6
4 I/O slot chassis Panel mount or 19” rackmount 396356-02-8
8 I/O slot chassis Panel mount or 19” rackmount 396356-01-0
Internal Power Supply Sequencer Module (PSSM)
12 V input power PSSM 396351-02-6
24 V input power PSSM 396351-01-8
Redundant I/O System
PSSM
24 V input power PSSM used with Redundant I/O system. See Page 5 396351-03-4
CPU (See Note 1) Comm Port Congurations (Note 3)
CPU with 16 MB of RAM 1 - ENET & 2 - RS 232 396359-01-9
CPU with 16 MB of RAM 1 - ENET & 3 - RS 232 & 1 - RS 485 (Note 2) 396359-06-0
CPU with 16 MB of RAM 1 - ENET & 2 - RS 232 & 2 - RS 485 (Note 2) 396359-07-8
CPU with 16 MB of RAM 3 - ENET & 3 - RS 232 & 1 - RS 485 (Note 2) 396359-05-1
CPU with 16 MB of RAM 3 - ENET & 2 - RS 232 & 2 - RS 485 (Note 2) 396359-12-4
I/O Expansion Rack CPU Comm Port Congurations (Note 3)
Comm CPU 2 - RS232 & 1 - ENET 396458-01-7
Comm CPU 1 RS 232, 1 - RS 485 & 1 - ENET 396458-02-5
